Thermal Insulation Solutions for Steam Systems and District Heating Infrastructure
SUM Maintenance Guard insulation covers are designed for continuous operation on valves and equipment with surface temperatures of up to 260°C. The outer layer is made of silicone-coated fiberglass fabric, providing resistance to weather conditions and most chemicals commonly encountered in industrial environments.
Chemical-Resistant Thermal Insulation Solutions
SUM Chemical Guard insulation covers, manufactured using PTFE-coated (Teflon-coated) fiberglass fabrics, offer high resistance to aggressive chemical substances such as acids, alkalis, solvents, and alcohols. They are suitable for industrial valves and equipment operating in both high- and low-temperature environments.
Thermal Insulation Solutions for Hazardous (EX) Areas
SUM Antistatic Guard insulation covers are designed for installation in hazardous (EX) areas. Thanks to an outer layer made of specialized fiberglass fabric coated with conductive PTFE (Teflon), combined with carefully engineered construction details, the covers are capable of dissipating electrostatic charges across their entire surface. As standard, they are also equipped with grounding connection points for earthing cables.
Hygienic Thermal Insulation Solutions – PZH Certified
SUM Higienic Guard insulation covers are a product range developed for applications in the food, cosmetics, and pharmaceutical industries, as well as in environments where strict hygiene requirements must be maintained in areas with product contact.
Thermal Insulation Solutions for Exhaust Systems and Turbines
SUM Exhaust Guard insulation covers are characterized by high temperature resistance ranging from 450°C to 1000°C, enabled by a wide selection of reinforced fabrics and insulation fillings made of fiberglass (HT, HTM), silica, and ceramic materials.
Thermal Insulation with Heating System – Active Protection Against Crystallization and Freezing
SUM Heating Guard insulation covers are not only passive insulation, but a complete protection system against crystallization and freezing. The heating cable is integrated with the inner layer of the cover, while an external electronic thermostat with a power supply cable is mounted on the outside—forming a ready-to-use plug-and-play system.
Fire-Resistant Thermal Insulation – Passive Fire Protection Solution
SUM Fire Guard insulation covers are designed to protect and significantly extend the failure-free operating time of critical infrastructure components in the event of a fire. The material composition and specifically engineered, tested construction are completely non-combustible and maintain structural integrity even after prolonged exposure to direct flames at temperatures of up to 1093°C.
Thermal Insulation for Cold Systems
SUM Anti-freeze Guard insulation covers are designed to meet the specific requirements of industrial cold systems such as ammonia, glycol, and chilled water circuits. These covers eliminate condensation and ice buildup, which commonly occur on unprotected valve components. They significantly reduce maintenance intervention time (no ice layer on valves) and improve the energy efficiency of distribution pipelines.
The tailor-made insulation cover technology is one of the most versatile and flexible insulation methods. SUM’s many years of experience, combined with implemented CAD/CAM digital technologies, enable us to meet virtually any challenge. We are open to demanding projects, develop prototypes, design new solutions, and support our clients with our expertise.
